Technical Sheet
Name | Data |
Model | GS1450 |
Sweeping width | 1450mm |
Cleaning width | 1080mm |
Sucking width | 1350mm |
Side brush size | 500mm*2 |
Main brush size | 790*300mm |
Clean brush size | 380mm*3 |
Working efficiency | 0-13050m²/h |
Driving speed | 0-9km/h |
Clean water tank | 280L |
Dirty water tank | 330L |
Dust bin size | 60L |
Working time | 6-8h |
Vacuum filter area | 4.2m² |
Battery | Lithium&Lead-acid battery |
Battery | 72V/200Ah |
Main brush motor power | 950W |
Side brush motor power | 90W*2 |
Clean brush motor power | 600W*3 |
Sucking motor power | 600W*2 |
Drive motor power | 2800W |
Side brush up&down motor | 20W |
Clean brush up&down motor | 55W |
Sucking up&down motor | 35W |
Fan motor | 95W |
Clean water pump power | 120W |
Weight | 1320kg |
Machine size | 2800*1460*1590mm |
Packing size | 2880*1540*1696mm |
Minimum rotary radius | 580mm |
