Technical Sheet
Name | Data |
Model | HS1400 |
Sweeping width | 1400mm |
Main brush size | 690*300mm |
Working efficiency | 0-9800m²/h |
Driving speed | 0-7km/h |
Water tank capacity | 90L |
Trash tank capacity | 180L |
Working speed | 4-5h |
Side brush diameter | 500mm*2 |
Filter area | 4.2m² |
Battery | Lithium&Lead-acid battery |
Battery | 48V/100Ah |
Driving motor | 1000W |
Main brush motor | 950W |
Side brush motor | 90W*2 |
Rod up*down motor | 20W*2 |
Electric dust motor | 120W |
Fan motor | 95W |
Weight | 430kg |
Machine size | 1740*1360*1320mm |
Packing size | 1800*1370*1510mm |
Minimum rotary radius | 580mm |
