Technical Sheet
Name | Data |
Model | HS2100 |
Sweeping width | 2100mm |
Main brush size | 790*300mm |
Working efficiency | 0-14350m²/h |
Driving speed | 0-7km/h |
Water tank capacity | 200L |
Trash tank capacity | 260L |
Working time | 4-5h |
Side brush diameter | 500mm*4 |
Filter area | 4.2m²*2 |
Battery | Lithium&Lead-acid battery |
Battery | 48V/100Ah |
Driving motor | 1200W |
Main brush motor | 950W |
Side brush motor | 90W*2+150W*2 |
Rod up*down motor | 20W*4 |
Electric dust motor | 120W*2 |
Fan motor | 95W*2 |
Weight | 840kg |
Machine size | 2600*2060*2130mm |
Packing size | 2650*2060*2290mm |
Minimum rotary radius | 960mm |
