Technical Sheet
Name | Data |
Model | HS2300 |
Sweeping width | 2300mm |
Main brush size | 790*300mm |
Working efficiency | 0-33000m²/h |
Driving speed | 0-15km/h |
Water tank capacity | 300L |
Trash tank capacity | 260L |
Working time | 4-5h |
Side brush diameter | 500mm*2+700mm*2 |
Filter area | 4.2m²*2 |
Battery | Lithium&Lead-acid battery |
Battery | 48V/200Ah |
Driving motor | 3000W |
Main brush motor | 950W |
Side brush motor | 90W*2+165W*2 |
Rod up*down motor | 20W*4 |
Electric dust motor | 120W*2 |
Fan motor | 95W*2 |
High-pressure washer motor | 1100W |
High-pressure washer pressure | 9Mpa (90kg) |
High-pressure washer fluency | 10.5L/min |
Weight | 1600kg |
Machine size | 3640*2280*2685mm |
Packing size | 3640*2280*2835mm |
Minimum rotary radius | 2280mm |
