Technical Sheet
Name | Data |
Model | HS1900 |
Sweeping width | 1900mm |
Main brush size | 790*300mm |
Working efficiency | 0-13650m²/h |
Driving speed | 0-7km/h |
Water tank capacity | 180L |
Trash tank capacity | 155L |
Working time | 4-5h |
Side brush diameter | 500mm*4 |
Filter area | 4.2m²*2 |
Battery | Lithium&Lead-acid battery |
Battery | 48V/100Ah |
Driving motor | 1200W |
Main brush motor | 950W |
Side brush motor | 90W*2 |
Rod up*down motor | 20W*2 |
Electric dust motor | 120W |
Fan motor | 95W*2 |
Weight | 670kg |
Machine size | 2600*1960*2050mm |
Packing size | 2600*2050*2200mm |
Minimum rotary radius | 670mm |
